Ni 050
Description
The manufacturer's name on the device
Carl Zeiss Jena
Interesting construction features
Information about the use of device
Information about the device condition
Basic data
VÚGTK:
S0025
Owner:
Národní technické muzeum
Manufacturer:
Carl Zeiss Jena
Made:
01.01.1970
Length:
80
mm
Width:
110
mm
Height:
109
mm
Weight:
980
g
S/N:
445801
Technical parameters
cross hairs:
telescope type:
non-removable
tripod connection:
tribrach
type of clamp:
endless
compensator:
yes
unite:
gon
elevation screw:
no
distance meter type:
optical
construction of the distance meter:
integrated
view in the telescope:
erected
variable telescope length:
no
telescope length with retracted eyepiece:
207
mm
telescope diameter:
45
mm
minimum telescope focusing distance:
830
mm
telescope magnification:
17
horizontal circle:
no
segment of the vertical circle:
no
cross level:
no
leveling vial:
no
striding level:
no
designed for work:
basic work
