levelling instrument – Reiss
Description
The manufacturer's name on the device
R. Reiss Liebenwerda
Interesting construction features
Information about the use of device
Information about the device condition
Basic data
VÚGTK:
S0011
Owner:
Národní technické muzeum
Manufacturer:
Reiss
Made:
01.01.1910
Length:
128
mm
Width:
141
mm
Height:
195
mm
Weight:
2390
g
S/N:
5039
Technical parameters
cross hairs:
telescope type:
non-removable
tripod connection:
tribrach
type of clamp:
clamp on the axis
compensator:
no
elevation screw:
no
view in the telescope:
inverted
variable telescope length:
yes
telescope length with retracted eyepiece:
297
mm
telescope length with extended eyepiece:
333
mm
telescope diameter:
41
mm
minimum telescope focusing distance:
3770
mm
telescope magnification:
25
horizontal circle:
no
segment of the vertical circle:
no
cross level:
no
leveling vial:
yes
length of leveling vial:
122
mm
bubble length of the leveling vial:
23
mm
striding level:
no
sensitivity of the striding level or leveling vial:
20
"
designed for work:
basic work
