Ni-D1
Description
The manufacturer's name on the device
MOM BUDAPEST
Interesting construction features
Information about the use of device
Information about the device condition
Basic data
VÚGTK:
S0119
Owner:
Vysoké učení technické v Brně
Manufacturer:
MOM
Made:
01.01.1970
Length:
103
mm
Width:
97
mm
Height:
180
mm
Weight:
1110
g
S/N:
915351
Technical parameters
cross hairs:
telescope type:
non-removable
tripod connection:
tribrach
type of clamp:
endless
compensator:
yes
unite:
gon
elevation screw:
no
distance meter type:
optical
construction of the distance meter:
integrated
view in the telescope:
inverted
variable telescope length:
no
telescope diameter:
25
mm
minimum telescope focusing distance:
1500
mm
telescope magnification:
17
horizontal circle:
yes
horizontal circle diameter:
92
mm
main reading scale of the horizontal circle:
index
number of reading scales of the horizontal circle:
1
the smallest segment of the horizontal circle:
20'
segment of the vertical circle:
no
cross level:
no
leveling vial:
no
striding level:
no
designed for work:
basic work
