Zeměměřické a astronomické přístroje používané na území ČR od 16. do konce 20. století
levelling instrument – Reiss
The manufacturer's name on the device
- R.Reiss Liebenwerda
- VÚGTK: S0145
- Owner: Hornicko-geologická fakulta, VŠB-TUO
- Manufacturer: Reiss
- Made: 01.01.1920
- Length: 360 mm
- Width: 142 mm
- Height: 220 mm
- Weight: 3920 g
- S/N: 3525
- cross hairs:
-
- telescope type: reversible
- tripod connection: tribrach
- type of clamp: clamp on the axis
- compensator: no
- elevation screw: no
- view in the telescope: inverted
- variable telescope length: yes
- telescope length with retracted eyepiece: 360 mm
- telescope length with extended eyepiece: 398 mm
- telescope diameter: 30 mm
- minimum telescope focusing distance: 5500 mm
- telescope magnification: 30
- horizontal circle: no
- segment of the vertical circle: no
- cross level: no
- leveling vial: yes
- length of leveling vial: 70 mm
- bubble length of the leveling vial: 25 mm
- striding level: no
- sensitivity of the striding level or leveling vial: 20 "
- designed for work: precise work
