levelling instrument – T. H. Schmidt G. Nochler
Description
The manufacturer's name on the device
T. H. Schmidt G. Nockler Halle a/S.
Interesting construction features
Information about the use of device
Information about the device condition
Basic data
VÚGTK:
S0149
Owner:
Hornicko-geologická fakulta, VŠB-TUO
Manufacturer:
T. H. Schmidt G. Nochler
Made:
01.01.1910
Length:
278
mm
Width:
145
mm
Height:
147
mm
Weight:
2040
g
S/N:
224
Technical parameters
cross hairs:
telescope type:
non-removable
tripod connection:
tribrach
type of clamp:
clamp on the axis
compensator:
no
elevation screw:
no
construction of the distance meter:
N/A
view in the telescope:
inverted
variable telescope length:
yes
telescope length with retracted eyepiece:
278
mm
telescope length with extended eyepiece:
310
mm
telescope diameter:
26
mm
minimum telescope focusing distance:
3500
mm
telescope magnification:
17
horizontal circle:
no
segment of the vertical circle:
no
cross level:
no
leveling vial:
yes
length of leveling vial:
102
mm
striding level:
no
designed for work:
basic work
