vytyčovací
Description
The manufacturer's name on the device
Interesting construction features
Information about the use of device
Information about the device condition
Basic data
VÚGTK:
S0312
Owner:
České vysoké učení technické v Praze - Stavební fakulta
Manufacturer:
Georg Buterschön
Made:
01.01.1900
Length:
218
mm
Width:
218
mm
Height:
275
mm
Weight:
3286
g
S/N:
Technical parameters
cross hairs:
telescope type:
special
tripod connection:
tribrach
type of clamp:
clamp on the axis
compensator:
no
the possibility of determining the elevation:
no
view in the telescope:
inverted
variable telescope length:
yes
telescope length with retracted eyepiece:
186
mm
telescope length with extended eyepiece:
210
mm
telescope diameter:
24
mm
type of optical plummet:
none
compass:
none
vertical circle:
no
segment of the vertical circle:
no
cross level:
no
leveling vial:
yes
length of leveling vial:
47
mm
bubble length of the leveling vial:
0
mm
striding level:
no
altitude buble:
no
designed for work:
special work
