other devices for measuring angle – Voigtländer
Description
The manufacturer's name on the device
J. C. Voigtländer in Wien
Interesting construction features
Information about the use of device
Information about the device condition
Basic data
VÚGTK:
S0081
Owner:
unpublished
Manufacturer:
Voigtländer
Made:
01.02.1880
Length:
378
mm
Width:
181
mm
Height:
140
mm
Weight:
2070
g
S/N:
Technical parameters
telescope type:
N/A
tripod connection:
special
type of clamp:
none
compensator:
no
unite:
° ' "
the possibility of determining the elevation:
no
construction of the distance meter:
N/A
altitude buble:
no
type of optical plummet:
none
compass:
none
horizontal circle:
yes
horizontal circle diameter:
295
mm
main reading scale of the horizontal circle:
vernier
the smallest segment of the horizontal circle:
5´
number of reading scales of the horizontal circle:
1
setting the horizontal circle to zero:
none
vertical circle:
no
segment of the vertical circle:
no
cross level:
no
striding level:
no
designed for work:
basic work
