theodolite – Wichmann
The manufacturer's name on the device
- cme - německý válečný kód firmy Gebrüder Wichmann Berlin
- VÚGTK: S0085
- Owner: unpublished
- Manufacturer: Wichmann
- Made: 01.01.1943
- Length: 173 mm
- Width: 147 mm
- Height: 334 mm
- Weight: 4270 g
- S/N: 211437
- cross hairs:
-
- telescope type: revolved
- tripod connection: tribrach
- type of clamp: clamp on the axis
- compensator: no
- unite: gon
- the possibility of determining the elevation: yes
- distance meter type: optical
- construction of the distance meter: integrated
- view in the telescope: inverted
- variable telescope length: no
- telescope length with retracted eyepiece: 146 mm
- telescope diameter: 39 mm
- minimum telescope focusing distance: 1400 mm
- telescope magnification: 25
- type of optical plummet: in the body of device
- compass: none
- horizontal circle diameter: 92 mm
- main reading scale of the horizontal circle: optical micrometer
- number of reading scales of the horizontal circle: 1
- the smallest segment of the horizontal circle: 30"
- setting the horizontal circle to zero: horizontal circle drive knob
- vertical circle: yes
- segment of the vertical circle: no
- vertical circle diameter: 66 mm
- main reading scale of the vertical circle: optical micrometer
- number of reading scales of the vertical circle: 1
- the smallest segment of the vertical circle: 30"
- cross level: no
- bubble length of the cross level/level perpendicular with line of collimation: 23 mm
- leveling vial: no
- striding level: no
- altitude buble: yes
- lenght of the altitude level: 62 mm
- sensitivity of the alidade level: 20 "
- designed for work: precise work
