Theo 2

The manufacturer's name on the device
  • Freiberger Präzissions-Mechanik

Interesting construction features

Information about the use of device

Information about the device condition

  • VÚGTK: S0113
  • Owner: Vysoké učení technické v Brně
  • Manufacturer: Freiberger Präzissions-Mechanik (FPM)
  • Made: 01.01.1960
  • Length: 200 mm
  • Width: 177 mm
  • Height: 290 mm
  • Weight: 5290 g
  • S/N: 12537

  • cross hairs:
  • NK_012
  • telescope type: revolved
  • tripod connection: tribrach
  • type of clamp: clamp on the axis
  • compensator: no
  • unite: ° ' "
  • the possibility of determining the elevation: yes
  • distance meter type: optical
  • construction of the distance meter: integrated
  • view in the telescope: inverted
  • variable telescope length: no
  • telescope length with retracted eyepiece: 178 mm
  • telescope diameter: 40 mm
  • minimum telescope focusing distance: 1350 mm
  • telescope magnification: 28
  • type of optical plummet: in tribrach
  • compass: none
  • main reading scale of the horizontal circle: micrometer scale
  • number of reading scales of the horizontal circle: 1
  • the smallest segment of the horizontal circle: 2"
  • setting the horizontal circle to zero: horizontal circle drive knob
  • vertical circle: yes
  • segment of the vertical circle: no
  • main reading scale of the vertical circle: micrometer scale
  • number of reading scales of the vertical circle: 1
  • the smallest segment of the vertical circle: 2"
  • cross level: no
  • length of the cross level/level perpendicular with line of collimation: 75 mm
  • bubble length of the cross level/level perpendicular with line of collimation: 22 mm
  • leveling vial: no
  • striding level: no
  • altitude buble: yes
  • sensitivity of the alidade level: 20" "
  • designed for work: precise work
