Zeměměřické a astronomické přístroje používané na území ČR od 16. do konce 20. století
EOK 2000
The manufacturer's name on the device
- Carl Zeiss Jena
- VÚGTK: S0116
- Owner: Vysoké učení technické v Brně
- Manufacturer: Carl Zeiss Jena
- Made: 01.01.1970
- Length: 350 mm
- Width: 304 mm
- Height: 288 mm
- Weight: 13210 g
- S/N: 405156
- cross hairs:
-
- telescope type: non-removable
- tripod connection: tribrach
- type of clamp: clamp on the axis
- compensator: yes
- striding level: no
- the possibility of determining the elevation: no
- distance meter type: electronic
- construction of the distance meter: integrated
- distance meter measuring range: 2000 m
- autoreduction of the length: no
- altitude buble: no
- view in the telescope: erected
- variable telescope length: no
- telescope length with retracted eyepiece: 350 mm
- telescope diameter: 35 mm
- minimum telescope focusing distance: 2050 mm
- telescope magnification: 18
- type of optical plummet: in the body of device
- horizontal circle: no
- vertical circle: no
- segment of the vertical circle: no
- cross level: no
- designed for work: precise work
