Ni 007
Description
The manufacturer's name on the device
Carl Zeiss Jena
Interesting construction features
Information about the use of device
Information about the device condition
Basic data
VÚGTK:
S0016
Owner:
Národní technické muzeum
Manufacturer:
Carl Zeiss Jena
Made:
01.01.1970
Length:
139
mm
Width:
159
mm
Height:
340
mm
Weight:
3960
g
S/N:
279391
Technical parameters
cross hairs:
telescope type:
non-removable
tripod connection:
tribrach
type of clamp:
clamp on the axis
compensator:
yes
unite:
gon
elevation screw:
no
distance meter type:
optical
construction of the distance meter:
integrated
view in the telescope:
erected
variable telescope length:
no
telescope diameter:
68
mm
minimum telescope focusing distance:
2180
mm
telescope magnification:
30
horizontal circle:
yes
main reading scale of the horizontal circle:
index
number of reading scales of the horizontal circle:
1
the smallest segment of the horizontal circle:
0,1 gon
segment of the vertical circle:
no
cross level:
no
leveling vial:
no
striding level:
no
sensitivity of the alidade level:
5'
"
designed for work:
precise work
