Ni 002
Description
The manufacturer's name on the device
VEB Carl Zeiss Jena
Interesting construction features
Information about the use of device
Information about the device condition
Basic data
VÚGTK:
S0021
Owner:
Národní technické muzeum
Manufacturer:
Carl Zeiss Jena
Made:
01.01.1970
Length:
160
mm
Width:
370
mm
Height:
312
mm
Weight:
6670
g
S/N:
429969
Technical parameters
cross hairs:
telescope type:
non-removable
tripod connection:
tribrach
type of clamp:
endless
compensator:
yes
unite:
gon
elevation screw:
no
distance meter type:
optical
construction of the distance meter:
integrated
view in the telescope:
erected
variable telescope length:
no
telescope length with retracted eyepiece:
375
mm
telescope diameter:
73
mm
minimum telescope focusing distance:
1980
mm
telescope magnification:
40
horizontal circle:
yes
main reading scale of the horizontal circle:
index
number of reading scales of the horizontal circle:
1
the smallest segment of the horizontal circle:
1'
segment of the vertical circle:
no
cross level:
no
leveling vial:
no
striding level:
no
designed for work:
high precise work
