Zeměměřické a astronomické přístroje používané na území ČR od 16. do konce 20. století

centrovač

The manufacturer's name on the device

Interesting construction features

Information about the use of device

Information about the device condition

  • VÚGTK: S0307
  • Owner: České vysoké učení technické v Praze - Stavební fakulta
  • Manufacturer: Feinmess Dresden
  • Made: 01.01.1970
  • Length: 65 mm
  • Width: 60 mm
  • Height: 75 mm
  • Weight: 788 g
  • S/N:

  • telescope type: non-removable
  • tripod connection: tribrach
  • type of clamp: clamp on the axis
  • compensator: no
  • the possibility of determining the elevation: no
  • elevation screw: no
  • view in the telescope: inverted
  • variable telescope length: no
  • telescope length with extended eyepiece: 121 mm
  • telescope diameter: 5 mm
  • type of optical plummet: none
  • compass: none
  • horizontal circle: no
  • vertical circle: no
  • segment of the vertical circle: no
  • cross level: no
  • length of the cross level/level parallel with line of collimation: 25 mm
  • bubble length of the cross level/level parallel with line of collimation: 6 mm
  • striding level: no
  • altitude buble: no
  • designed for work: special work
