levelling instrument – J. & J. Frič
The manufacturer's name on the device
- VÚGTK: S0322
- Owner: České vysoké učení technické v Praze - Stavební fakulta
- Manufacturer: J. & J. Frič
- Made: 01.01.1900
- Length: 198 mm
- Width: 81 mm
- Height: 110 mm
- Weight: 480 g
- S/N:
- cross hairs:
-
- telescope type: non-removable
- tripod connection: pin
- type of clamp: clamp on the axis
- compensator: no
- elevation screw: yes
- view in the telescope: inverted
- variable telescope length: yes
- telescope length with retracted eyepiece: 190 mm
- telescope length with extended eyepiece: 198 mm
- telescope diameter: 23 mm
- horizontal circle: no
- segment of the vertical circle: no
- cross level: no
- leveling vial: yes
- length of leveling vial: 80 mm
- bubble length of the leveling vial: 23 mm
- striding level: no
- designed for work: basic work
