levelling instrument – Kern

The manufacturer's name on the device

Interesting construction features

Information about the use of device

Information about the device condition

  • VÚGTK: S0345
  • Owner: České vysoké učení technické v Praze - Stavební fakulta
  • Manufacturer: Kern
  • Made: 01.01.1920
  • Length: 340 mm
  • Width: 168 mm
  • Height: 310 mm
  • Weight: 3014 g
  • S/N: 24914

  • cross hairs:
  • NK_001
  • telescope type: reversible
  • tripod connection: tribrach
  • type of clamp: clamp on the axis
  • compensator: no
  • elevation screw: yes
  • variable telescope length: yes
  • telescope length with extended eyepiece: 340 mm
  • telescope diameter: 30 mm
  • horizontal circle: no
  • segment of the vertical circle: no
  • cross level: no
  • leveling vial: yes
  • striding level: no
  • designed for work: precise work
