Ni 025
Description
The manufacturer's name on the device
Interesting construction features
Information about the use of device
Information about the device condition
Basic data
VÚGTK:
S0350
Owner:
České vysoké učení technické v Praze - Stavební fakulta
Manufacturer:
Carl Zeiss Jena
Made:
01.01.1960
Length:
188
mm
Width:
100
mm
Height:
130
mm
Weight:
1455
g
S/N:
182467
Technical parameters
cross hairs:
telescope type:
non-removable
tripod connection:
tribrach
type of clamp:
endless
compensator:
yes
unite:
gon
elevation screw:
no
distance meter type:
optical
construction of the distance meter:
integrated
view in the telescope:
erected
variable telescope length:
no
telescope length with extended eyepiece:
191
mm
telescope diameter:
30
mm
horizontal circle:
yes
horizontal circle diameter:
70
mm
main reading scale of the horizontal circle:
reading microscope
number of reading scales of the horizontal circle:
1
the smallest segment of the horizontal circle:
1 gon / 0,5 gon
segment of the vertical circle:
no
cross level:
no
leveling vial:
no
striding level:
no
designed for work:
basic work
