BRT 006
The manufacturer's name on the device
- Carl Zeiss Jena
- VÚGTK: S0061
- Owner: unpublished
- Manufacturer: Carl Zeiss Jena
- Made: 01.01.1964
- Length: 160 mm
- Width: 570 mm
- Height: 260 mm
- Weight: 6980 g
- S/N: 190238
- cross hairs:
-
- telescope type: special
- tripod connection: tribrach
- type of clamp: clamp on the axis
- compensator: no
- unite: gon
- distance meter type: optomechanical
- construction of the distance meter: integrated
- distance meter measuring range: 60 m
- autoreduction of the length: yes
- view in the telescope: erected
- variable telescope length: no
- telescope diameter: 30 mm
- minimum telescope focusing distance: 1800 mm
- telescope magnification: 15
- type of optical plummet: none
- compass: none
- horizontal circle diameter: 115 mm
- main reading scale of the horizontal circle: index
- number of reading scales of the horizontal circle: 1
- the smallest segment of the horizontal circle: 50mgon
- setting the horizontal circle to zero: horizontal circle drive knob
- vertical circle: no
- segment of the vertical circle: yes
- segment's range of vertical circle: 50 gon - 150 gon
- main reading scale of the vertical circle: index
- number of reading scales of the vertical circle: 1
- the smallest segment of the vertical circle: 50 mgon
- cross level: no
- length of the cross level/level parallel with line of collimation: 55 mm
- bubble length of the cross level/level parallel with line of collimation: 15 mm
- altitude buble: no
- leveling vial: no
- striding level: no
- sensitivity of the alidade level: 80 "
- designed for work: low precise work
