Eklimetr
Description
The manufacturer's name on the device
Meopta
Interesting construction features
Information about the use of device
Information about the device condition
Basic data
VÚGTK:
S0062
Owner:
unpublished
Manufacturer:
Meopta
Made:
01.01.1960
Length:
510
mm
Width:
185
mm
Height:
160
mm
Weight:
3670
g
S/N:
80814
Technical parameters
cross hairs:
telescope type:
flip over
tripod connection:
special
type of clamp:
clamp on the axis
compensator:
no
unite:
° ' "
the possibility of determining the elevation:
yes
elevation screw:
no
distance meter type:
optical
construction of the distance meter:
integrated
autoreduction of the length:
no
view in the telescope:
inverted
variable telescope length:
no
telescope length with retracted eyepiece:
220
mm
telescope diameter:
47
mm
minimum telescope focusing distance:
1800
mm
telescope magnification:
25
type of optical plummet:
none
compass:
none
horizontal circle:
no
setting the horizontal circle to zero:
none
vertical circle:
yes
segment of the vertical circle:
no
vertical circle diameter:
100
mm
main reading scale of the vertical circle:
vernier
number of reading scales of the vertical circle:
1
the smallest segment of the vertical circle:
1'
cross level:
no
length of the cross level/level perpendicular with line of collimation:
46
mm
bubble length of the cross level/level perpendicular with line of collimation:
18
mm
length of leveling vial:
69
mm
bubble length of the leveling vial:
26
mm
striding level:
no
sensitivity of the striding level or leveling vial:
10
"
sensitivity of the alidade level:
40
"
altitude buble:
yes
lenght of the altitude level:
66
mm
designed for work:
special work
