Te-D1
The manufacturer's name on the device
- MOM BUDAPEST
- VÚGTK: S0067
- Owner: unpublished
- Manufacturer: MOM
- Made: 01.01.1975
- Length: 180 mm
- Width: 152 mm
- Height: 245 mm
- Weight: 4880 g
- S/N: 826694
- cross hairs:
-
- telescope type: revolved
- tripod connection: tribrach
- type of clamp: clamp on the axis
- compensator: no
- unite: gon
- the possibility of determining the elevation: yes
- distance meter type: optical
- construction of the distance meter: integrated
- view in the telescope: inverted
- variable telescope length: no
- telescope length with retracted eyepiece: 180 mm
- telescope diameter: 50 mm
- minimum telescope focusing distance: 2000 mm
- telescope magnification: 23
- type of optical plummet: in the body of device
- compass: none
- horizontal circle diameter: 110 mm
- main reading scale of the horizontal circle: optical micrometer
- number of reading scales of the horizontal circle: 1
- the smallest segment of the horizontal circle: 2"
- setting the horizontal circle to zero: horizontal circle drive knob
- vertical circle: yes
- segment of the vertical circle: no
- vertical circle diameter: 85 mm
- main reading scale of the vertical circle: optical micrometer
- number of reading scales of the vertical circle: 1
- the smallest segment of the vertical circle: 2"
- cross level: no
- length of the cross level/level perpendicular with line of collimation: 55 mm
- bubble length of the cross level/level perpendicular with line of collimation: 15 mm
- leveling vial: no
- striding level: no
- altitude buble: yes
- sensitivity of the alidade level: 30 "
- designed for work: precise work
