Zeměměřické a astronomické přístroje používané na území ČR od 16. do konce 20. století
Instruments
Manufacturers
About project
instruments
levelling instrument
Ni 025
manufacturers
Carl Zeiss Jena
Ni 025
×
×
×
×
×
Previous
Next
Ni 025
Description
The manufacturer's name on the device
Carl Zeiss Jena
Interesting construction features
Information about the use of device
Information about the device condition
Basic data
VÚGTK:
S0071
Owner:
unpublished
Manufacturer:
Carl Zeiss Jena
Made:
01.01.1963
Length:
195
mm
Width:
105
mm
Height:
146
mm
Weight:
1700
g
S/N:
469130
Technical parameters
cross hairs:
telescope type:
non-removable
tripod connection:
tribrach
type of clamp:
endless
compensator:
yes
unite:
° ' "
distance meter type:
optical
construction of the distance meter:
integrated
view in the telescope:
erected
variable telescope length:
no
telescope length with retracted eyepiece:
190
mm
telescope diameter:
37
mm
minimum telescope focusing distance:
1450
mm
telescope magnification:
23
main reading scale of the horizontal circle:
index
number of reading scales of the horizontal circle:
1
the smallest segment of the horizontal circle:
10´
