Elta 2

The manufacturer's name on the device
  • Zeiss Oberkochen

Interesting construction features

Information about the use of device

Information about the device condition

  • VÚGTK: S0074
  • Owner: unpublished
  • Manufacturer: Zeiss Oberkochen
  • Made: 01.01.1966
  • Length: 320 mm
  • Width: 260 mm
  • Height: 180 mm
  • Weight: 6380 g
  • S/N: 180938

  • cross hairs:
  • NK_017
  • telescope type: rotated
  • tripod connection: tribrach
  • type of clamp: clamp on the axis
  • compensator: yes
  • unite: gon
  • the possibility of determining the elevation: yes
  • distance meter type: electronic
  • construction of the distance meter: integrated
  • distance meter measuring range: 1600 m
  • view in the telescope: erected
  • telescope diameter: 50 mm
  • minimum telescope focusing distance: 1200 mm
  • telescope magnification: 30
  • type of optical plummet: in the body of device
  • main reading scale of the horizontal circle: electronic
  • the smallest segment of the horizontal circle: 0,2 mgon / 1"
  • setting the horizontal circle to zero: electronic
  • vertical circle: yes
  • main reading scale of the vertical circle: electronic
  • the smallest segment of the vertical circle: 0,2 mgon / 1"
  • sensitivity of the alidade level: 30" "
  • designed for work: precise work
