Dimes 002
Description
The manufacturer's name on the device
Carl Zeiss Jena
Interesting construction features
Information about the use of device
Information about the device condition
Basic data
VÚGTK:
S0086
Owner:
unpublished
Manufacturer:
Carl Zeiss Jena
Made:
01.01.1953
Length:
90
mm
Width:
73
mm
Height:
64
mm
Weight:
260
g
S/N:
110023
Technical parameters
tripod connection:
N/A
type of clamp:
none
compensator:
no
striding level:
no
the possibility of determining the elevation:
no
distance meter type:
optomechanical
construction of the distance meter:
attachable
distance meter measuring range:
180
m
autoreduction of the length:
no
altitude buble:
no
variable telescope length:
no
telescope length with retracted eyepiece:
73
mm
telescope diameter:
46
mm
type of optical plummet:
none
horizontal circle:
no
setting the horizontal circle to zero:
none
vertical circle:
no
segment of the vertical circle:
no
cross level:
no
designed for work:
basic work
