Teletop
The manufacturer's name on the device
- Carl Zeiss Jena Teletop 6x
- VÚGTK: S0100
- Owner: Národní technické muzeum
- Manufacturer: Carl Zeiss Jena
- Made: 01.01.1950
- Length: 530 mm
- Width: 204 mm
- Height: 196 mm
- Weight: 2190 g
- S/N: 91497
- cross hairs:
-
- telescope type: special
- tripod connection: tribrach
- type of clamp: clamp on the axis
- compensator: no
- unite: ° ' "
- distance meter type: optomechanical
- construction of the distance meter: integrated
- distance meter measuring range: 80 m
- autoreduction of the length: yes
- view in the telescope: erected
- variable telescope length: no
- telescope length with retracted eyepiece: 170 mm
- telescope diameter: 20 mm
- telescope magnification: 6
- type of optical plummet: none
- compass: integrated
- compass design: circle
- compass diameter: 70 mm
- smallest division of the compass scale: 1´
- main reading scale of the horizontal circle: index
- number of reading scales of the horizontal circle: 1
- setting the horizontal circle to zero: none
- vertical circle: no
- segment of the vertical circle: yes
- segment's range of vertical circle: +-40
- vertical circle diameter: 85 mm
- main reading scale of the vertical circle: index
- number of reading scales of the vertical circle: 1
- the smallest segment of the vertical circle: 1°
- cross level: no
- altitude buble: no
- leveling vial: yes
- length of leveling vial: 38 mm
- bubble length of the leveling vial: 10 mm
- striding level: no
- sensitivity of the striding level or leveling vial: 120 "
- designed for work: basic work
