theodolite – Fennel
The manufacturer's name on the device
- Otto Fennel Söhne in Cassel D.R.P. No122901
- VÚGTK: S0137
- Owner: Hornicko-geologická fakulta, VŠB-TUO
- Manufacturer: Fennel
- Made: 01.01.1900
- Length: 375 mm
- Width: 215 mm
- Height: 290 mm
- Weight: 6930 g
- S/N: 5358; D.R.P. 122901
- cross hairs:
-
- telescope type: reversible
- tripod connection: tribrach
- type of clamp: clamp on the axis
- compensator: no
- unite: ° ' "
- the possibility of determining the elevation: yes
- distance meter type: optical
- construction of the distance meter: integrated
- view in the telescope: inverted
- variable telescope length: yes
- telescope length with retracted eyepiece: 375 mm
- telescope length with extended eyepiece: 415 mm
- telescope diameter: 35 mm
- minimum telescope focusing distance: 3200 mm
- telescope magnification: 22
- type of optical plummet: none
- compass: none
- horizontal circle diameter: 170 mm
- main reading scale of the horizontal circle: vernier
- number of reading scales of the horizontal circle: 2
- the smallest segment of the horizontal circle: 1'
- setting the horizontal circle to zero: repeating
- vertical circle: no
- segment of the vertical circle: no
- cross level: yes
- length of the cross level/level parallel with line of collimation: 65 mm
- bubble length of the cross level/level parallel with line of collimation: 15 mm
- length of the cross level/level perpendicular with line of collimation: 65 mm
- bubble length of the cross level/level perpendicular with line of collimation: 15 mm
- leveling vial: yes
- length of leveling vial: 100 mm
- bubble length of the leveling vial: 30 mm
- striding level: no
- altitude buble: no
- sensitivity of the striding level or leveling vial: 35 "
- sensitivity of the alidade level: 120 "
- designed for work: basic work
