Zeměměřické a astronomické přístroje používané na území ČR od 16. do konce 20. století

RK

The manufacturer's name on the device
  • Kern Suisse Switzerland

Interesting construction features

Information about the use of device

Information about the device condition

  • VÚGTK: S0240
  • Owner: České vysoké učení technické v Praze - Stavební fakulta
  • Manufacturer: Kern
  • Made: 01.01.1965
  • Length: 292 mm
  • Width: 128 mm
  • Height: 206 mm
  • Weight: 3140 g
  • S/N: 82403

  • cross hairs:
  • NK_048
  • telescope type: special
  • tripod connection: N/A
  • type of clamp: clamp on the axis
  • compensator: no
  • distance meter type: optomechanical
  • construction of the distance meter: integrated
  • autoreduction of the length: yes
  • view in the telescope: erected
  • variable telescope length: no
  • telescope diameter: 44 mm
  • minimum telescope focusing distance: 2800 mm
  • telescope magnification: 25
  • type of optical plummet: none
  • compass: none
  • vertical circle: yes
  • main reading scale of the vertical circle: index
  • number of reading scales of the vertical circle: 1
  • cross level: yes
  • length of the cross level/level parallel with line of collimation: 54 mm
  • bubble length of the cross level/level parallel with line of collimation: 8 mm
  • length of the cross level/level perpendicular with line of collimation: 54 mm
  • bubble length of the cross level/level perpendicular with line of collimation: 8 mm
  • altitude buble: no
  • leveling vial: no
  • striding level: no
  • sensitivity of the alidade level: 90 "
  • designed for work: basic work
