Redta 002
The manufacturer's name on the device
- VÚGTK: S0360
- Owner: České vysoké učení technické v Praze - Stavební fakulta
- Manufacturer: Carl Zeiss Jena
- Made: 01.01.1955
- Length: 307 mm
- Width: 160 mm
- Height: 290 mm
- Weight: 5343 g
- S/N: 114631
- cross hairs:
-
- telescope type: flip over
- tripod connection: tribrach
- type of clamp: clamp on the axis
- compensator: no
- unite: gon
- distance meter type: optical
- construction of the distance meter: integrated
- distance meter measuring range: 170 m
- autoreduction of the length: yes
- view in the telescope: erected
- variable telescope length: no
- telescope length with extended eyepiece: 307 mm
- telescope diameter: 38 mm
- minimum telescope focusing distance: 2600 mm
- telescope magnification: 25
- compass: none
- horizontal circle diameter: 110 mm
- main reading scale of the horizontal circle: reading microscope
- number of reading scales of the horizontal circle: 1
- the smallest segment of the horizontal circle: 1 gon / 10 mgon
- setting the horizontal circle to zero: circle clamp
- vertical circle: yes
- vertical circle diameter: 75 mm
- main reading scale of the vertical circle: reading microscope
- number of reading scales of the vertical circle: 1
- the smallest segment of the vertical circle: 1 gon / 10 mgon
- cross level: no
- length of the cross level/level perpendicular with line of collimation: 30 mm
- bubble length of the cross level/level perpendicular with line of collimation: 18 mm
- altitude buble: yes
- lenght of the altitude level: 30 mm
- bubble length of the altitude level: 18 mm
- leveling vial: yes
- length of leveling vial: 34 mm
- bubble length of the leveling vial: 18 mm
- striding level: no
- sensitivity of the striding level or leveling vial: 30 "
- sensitivity of the alidade level: 30 "
- sensitivity of the altitude level: 30 "
- designed for work: basic work
