Theo 010B
Description
The manufacturer's name on the device
Carl Zeiss Jena
Interesting construction features
Information about the use of device
Information about the device condition
Basic data
VÚGTK:
S0065
Owner:
unpublished
Manufacturer:
Carl Zeiss Jena
Made:
01.01.1980
Length:
190
mm
Width:
170
mm
Height:
326
mm
Weight:
4650
g
S/N:
104306
Technical parameters
cross hairs:
telescope type:
revolved
tripod connection:
tribrach
type of clamp:
peripheral clamp
compensator:
yes
unite:
gon
the possibility of determining the elevation:
yes
distance meter type:
optical
construction of the distance meter:
integrated
view in the telescope:
erected
variable telescope length:
no
telescope length with retracted eyepiece:
180
mm
telescope diameter:
45
mm
minimum telescope focusing distance:
1500
mm
telescope magnification:
28
type of optical plummet:
in the body of device
compass:
none
main reading scale of the horizontal circle:
optical micrometer
number of reading scales of the horizontal circle:
1
the smallest segment of the horizontal circle:
2"
setting the horizontal circle to zero:
horizontal circle drive knob
vertical circle:
yes
main reading scale of the vertical circle:
optical micrometer
number of reading scales of the vertical circle:
1
the smallest segment of the vertical circle:
2"
cross level:
no
length of the cross level/level perpendicular with line of collimation:
65
mm
bubble length of the cross level/level perpendicular with line of collimation:
23
mm
leveling vial:
no
striding level:
no
altitude buble:
no
sensitivity of the alidade level:
20
"
designed for work:
precise work
