theodolite – Breithaupt
The manufacturer's name on the device
- VÚGTK: S0268
- Owner: České vysoké učení technické v Praze - Stavební fakulta
- Manufacturer: Breithaupt
- Made: 01.01.1920
- Length: 147 mm
- Width: 122 mm
- Height: 231 mm
- Weight: 2265 g
- S/N: 33661
- cross hairs:
-
- telescope type: revolved
- tripod connection: tribrach
- type of clamp: clamp on the axis
- compensator: no
- unite: ° ' "
- the possibility of determining the elevation: yes
- distance meter type: optical
- construction of the distance meter: integrated
- view in the telescope: inverted
- variable telescope length: yes
- telescope length with retracted eyepiece: 132 mm
- telescope length with extended eyepiece: 147 mm
- telescope diameter: 18 mm
- minimum telescope focusing distance: 1400 mm
- type of optical plummet: none
- compass: integrated
- compass design: circle
- compass diameter: 71 mm
- smallest division of the compass scale: 1°
- setting the horizontal circle to zero: none
- vertical circle: yes
- vertical circle diameter: 76 mm
- main reading scale of the vertical circle: vernier
- number of reading scales of the vertical circle: 1
- the smallest segment of the vertical circle: 1° / 1'
- cross level: no
- leveling vial: yes
- length of leveling vial: 30 mm
- bubble length of the leveling vial: 15 mm
- striding level: no
- altitude buble: no
- sensitivity of the alidade level: krabicová "
- designed for work: basic work
